Quick Details

  • Size: 1/2"-80"
  • Material: Stainless Steel
  • Standard: ANSI, ANSI
  • Place of Origin: Shandong, China (Mainland)
  • Model Number: DN100
  • Brand Name: BETOOR
  • Standard or Nonstandard: Standard
  • Surface treatment: Sand Blasting
  • Application: Chemical
  • Product Keywords: flange,special flange,solid flange

Packaging & Delivery

Packaging Details Wooden case with Steel plates for protection
Delivery Time 15 days after Payment Confirmation
Product Description

Cheap solid stainless steel flange

Product details

StandardANSI
Surface treatmentSand Blasting
ApplicationChemical
Product Keywordsflange,special flange,solid flange


Quality assurance:
1.Supply Flange Dimension DN15 - DN600 (1/2" - 24") for Plate Flange, Forged Flange.
2.Flange Material Carbon Steel: ASTM A105, A181, A350 LF1, A350LF2, A350LF3, A36, A234 WPB, Q235B, 20#, 20Mn.
3.Flange Material Stainless Steel: ASTM A182 F304, F304L, F316, F316L, F321 etc.
4.Flange Anti Rust: Anti Rust Oil, Black Paint, Yellow Paint Coating, Hot Dipped Galvanized, Cold Galvanized etc.
5.Flange Monthly Output: 3000 tons per Month.
6.Flange Delivery Terms: CIF, CFR, FOB, EXW, transport by air, by sea, by express DHL, FedEx, TNT, EMS etc.
7.Flange Payment Terms: Wire Transfer (T/T), Irrevocable L/C at Sight etc.
8.Flange Minimum Order Quantity (MOQ): 1Ton or 100Pcs per size.
9.Quality Guarantee: EN10204 3.1 Certificate, Mill Certificate, Third Party Inspection, Free Replacement Service.





Flange Dimensions & Approximate Masses / Flange Weight
Table ANSI, ASME, ASA, B16.5 150lb/sq.in. Plate Ring Flange RF
øDbgmJkHoleslKg.
1/2"88,911,134,930,222,360,3415,90,400
3/4"98,412,742,938,127,769,8415,90,700
1"107,914,350,849,234,579,4415,90,800
1 1/4"117,515,963,558,843,288,9415,91,100
1 1/2"127,017,573,065,149,598,4415,91,400
2"152,419,092,177,862,0120,6419,02,200
2 1/2"177,822,2104,890,574,7139,7419,03,600
3"190,523,8127,0107,990,7152,4419,04,100
3 1/2"215,923,8139,7122,2103,4177,8819,05,200
4"228,623,8157,2134,9116,1190,5819,05,600
5"254,023,8185,7163,6143,8215,9822,26,300
6"279,425,4215,9192,1170,7241,3822,27,500
8"342,928,6269,9246,1221,5298,4822,212,600
10"406,430,2323,8304,8276,3361,91225,418,500
12"482,631,7381,0365,1327,1431,81225,528,000
14"533,434,9412,7400,0359,1476,21228,636,000
16"596,936,5469,9457,2410,5539,71628,646,000
18"635,039,7533,4504,8461,8577,81631,750,000
20"698,542,9584,2558,8513,1635,02031,764,000
22"749,346,0641,2609,6564,4692,12034,972,000
24"812,847,6692,1663,6615,9749,32034,989,000






Table ANSI, ASME, ASA, B16.5 300lb/sq.in. Plate Flange RF
øDbgmJkHoleslKg.
1/2"95,614,334,938,122,366,7415,90,700
3/4"117,515,942,947,627,782,5419,01,100
1"123,817,550,854,034,588,9419,01,400
1 1/4"133,319,063,563,543,298,4419,01,800
1 1/2"155,620,673,069,849,5114,3422,22,600
2"165,122,292,184,162,0127,0819,03,400
2 1/2"190,525,4104,8100,074,7149,2822,24,400
3"209,528,6127,0117,590,7168,3822,26,100
3 1/2"228,630,2139,7133,3103,4184,1822,27,500
4"254,031,7157,2146,0116,1200,0822,210,100
5"279,434,9185,7177,8143,8234,9822,212,500
6"317,536,5215,9206,4170,7269,91222,214,100
8"381,041,3269,9260,3221,5330,21225,424,800
10"444,547,6323,8320,7276,3387,31628,637,100
12"520,750,8381,0374,6327,1450,81631,750,000
14"584,254,0412,7425,4359,1514,32031,770,000
16"647,757,1469,9482,6410,5571,52034,990,000
18"711,260,3533,4533,4461,8628,62434,9112,000
20"774,763,5584,2584,2513,1685,82434,9133,000
22"838,266,7641,2641,2564,4742,92441,3197,000
24"914,469,8692,1701,7615,9812,82441,3208,000
NOTE:
        1. Class 300 flanges except Lap Joint will be furnished with 0.06 (1.6mm) raised face, which is included in ‘Thickness’ (C) and ‘Length through Hub’ (Y1), (Y3).
2. For Slip-on, Threaded, Socket Welding and Lap Joint Flanges, the hubs can be shaped either vertical from base to top or tapered within the limits of 7 degrees.
3. Blind Flanges may be made with the same hub as that used for Slip-on Flanges or without hub.
4. The gasket surface and backside (bearing surface for bolting) are made parallel within 1 degree. To accomplish parallelism, spot facing is carried out according to MSS SP-9, without reducing thickness (C).
5. Depth of Socket (D) is covered by ANSI B 16.5 only in sizes through 3 inch, over 3 inch is at the manufacturer’s option.





NOTE:
        1. Class 600 flanges except Lap Joint will be furnished with 0.25 (6.35mm) raised face, which is not included in ‘Thickness’ (C) and ‘Length through Hub’ (Y1), (Y3).
2. For Slip-on, Threaded, Socket Welding and Lap Joint Flanges, the hubs can be shaped either vertical from base to top or tapered within the limits of 7 degrees.
3. Blind Flanges may be made with the same hub as that used for Slip-on Flanges or without hub.
4. The gasket surface and backside (bearing surface for bolting) are made parallel within 1 degree. To accomplish parallelism, spot facing is carried out according to MSS SP-9, without reducing thickness (C).
5. Dimensions of sizes 1/2 through 3 1/2 are the same as for Class 400 Flanges.
6. Depth of Socket (D) is covered by ANSI B 16.5 only in sizes through 3 inch, over 3 inch is at the manufacturer’s option.

Production Capacity & Purchase Details

1.Supply Flange Dimension DN15 - DN600 (1/2" - 24") for Plate Flange, Forged Flange.
2.Flange Material Carbon Steel: ASTM A105, A181, A350 LF1, A350LF2, A350LF3, A36, A234 WPB, Q235B, 20#, 20Mn.
3.Flange Material Stainless Steel: ASTM A182 F304, F304L, F316, F316L, F321 etc.
4.Flange Anti Rust: Anti Rust Oil, Black Paint, Yellow Paint Coating, Hot Dipped Galvanized, Cold Galvanized etc.
5.Flange Monthly Output: 3000 tons per Month.
6.Flange Delivery Terms: CIF, CFR, FOB, EXW, transport by air, by sea, by express DHL, FedEx, TNT, EMS etc.
7.Flange Payment Terms: Wire Transfer (T/T), Irrevocable L/C at Sight etc.
8.Flange Minimum Order Quantity (MOQ): 1Ton or 100Pcs per size.
9.Quality Guarantee: EN10204 3.1 Certificate, Mill Certificate, Third Party Inspection, Free Replacement Service.






Company Information

ABOUT US

1. We have many experience in CNC machining service
2. We can accept small order for the beginning
3. Sample orcer can be finished in one week

10 YEARS EXPERIENCE

1. Top quality guaranteed by skilled workers, managing system and status of facilities.
2. We have many long cooperation supplier. supply ONE-STOP service
3. Customized size and spec /OEM.ODM available

PROVIDE ONE-STOP SERVICE

1. Our wokers are all professional and all can speack ENGLISH
2. 100% inspect before delivery

Certifications

security guaranteed 100%

Protect Your Payment, Secure Your Order

Our Advantages

10 years experience

With over 10 years of experience in this industry, Zibo betOor Stainless Steel Co., Ltd.

OEM&ODM

According to customer requirements and products, ODM/OEM services to customers around the world.

Quality assurance

Product quality assurance, with a product license, to provide the perfect after-sales service.

Wide Supply Range

Professional technical team from Flange, Pipe Fitting, Valves,Sanitary Fitting to Project Applyment

Packaging & Shipping

Packing & Delivery:


1. Flange Delivery Terms: CIF, CFR, FOB, EXW, transport by air, by sea, by express DHL, FedEx, TNT, EMS etc.
2. Flange Payment Terms: Wire Transfer (T/T), Irrevocable L/C at Sight etc.
3. Flange Minimum Order Quantity (MOQ): 1Ton or 100Pcs per size.
4. Quality Guarantee: EN10204 3.1 Certificate, Mill Certificate, Third Party Inspection, Free Replacement Service.

DELIVERY TIME:

3-20 days after confirming order,detail delivery date should be decided according to
production season and order quantity.
